Carbon Fiber Composite Materials
Nan Pao Carbon Fiber Composite Materials department using our self-develop technologies to develop our own Halogen Free, Fire Retardant Resistant Eco-friendly Carbon Fiber Composite Material. The strength of our Carbon Fiber Composite Materials outperform other same level products by 25% to 40%.
The excellent formability can cut down the cost of appreance processing. Remodelable Carbon Fiber Composite Materials present the innovative processing, not only decreasing defect rate but decreasing the processes and cost! We make impossible possible!
◆Features of Carbon Fiber Composite Materials:
1. Next generation and innovation product, Good for CFRP prepreg & laminate composites.
2. Special hybrid thermal cured polymer (Epoxy Polymer-Matrix).
3. Fire Resistant, meet UL-94V0.
4. Self cured, no Hardener required.
5. Halogen Free, meet RoHS 2.0 & IEC.
6. Excellent yield rate, reduce cost.
◆Product categories of Carbon Fiber Composites Materials:
1. High Performance Halogen Free & Fire-Resistant Carbon Fiber Prepregs.
2. High Performance Halogen Free & Fire-Resistant Carbon Fiber Plates.
3. Formable Halogen Free & Fire-Resistant Carbon Fiber Plates.
◆Specifications of Carbon Fiber Composite Materials:
A. High Performance Halogen Free & Fire-Resistant Carbon Fiber Prepregs.
1. Uni-Direction or Woven Fabrics.
2. CF Brand:Compatible with main carbon fiber brand.
3. FAW:UD – 60, 75, 100, 125, 150; 3K – 200.
4. Resin Content:UD – 28~37%, Woven – 37~47%.
5. Cured:Thermal, Hot-melt.
6. Forming:Compression Molding, Auto-clave, Vacuum Bag.
B. Halogen Free & Fire-Resistant Carbon Fiber Plates.
1. Standard Type:NN-2600 series.
2. High Strength Type:NC-2600 series.
3. Formable Type: NR-2600 series.
4. Standard size (mm):490 x 490, 500 x 1000.
5. Thickness (mm):0.2, 0.4, 0.6, 0.8, 1.0, 1.2, 1.5, 2.0, 2.5, 3.0, 3.5, 4.0, 4.5, 5.0, 5.5, 6.0.
6. Plate laminated construction is customized.
◆Applications of Carbon Fiber Composites Materials:
A. High Performance Halogen Free & Fire-Resistant Carbon Fiber Prepreg.
1. Automotive: Door, Roof, Roof Bow, Instrument dashboard, Chair, Door Handles, Door Panel, Back Mirror Housing, Aero Kit, Bus Deck. Plate, Bus Partition, Motorcycle Parts...
2. Railway: Partition.
3. Sports: Bicycle Frame, Bicycle Handles, Bicycle Fork, Golf Shaft, Golf Crown, Badminton Racket, Tennis Rackets, Fishing Rod...
4. General Industries: Pip, Plate, Housing, Parts, Structure Parts.
5. Others: Marine Partition.
B. High Performance Halogen Free & Fire-Resistant Carbon Fiber Plates.
1. Automotive:Door, Roof, Roof Bow, Instrument dashboard, Chair, Door Handles, Door Panel, Back Mirror Housing, Aero Kit, Bus Deck Plate, Bus Partition, Motorcycle Parts...
2. Sports:Bicycle Frame, Bicycle Handles, Bicycle Fork, Golf Shaft, Golf Crown, Badminton Racket, Tennis Rackets, Fishing Rod...
3. General Industries:Pip, Plate, Housing, Parts, Structure Parts.
4. Remote Control Model: Body Frame, Parts.
5. UAV: Body Frame, Parts.
C. Formable Halogen Free & Fire-Resistant Carbon Fiber Plates.
1. Housing or Plain Structure Parts for Aerospace, Automotive, Railway, Marine, Mobile Device and General Industries.
2. UAV Body Frame.
3. Mobile Device Housing (Laptop, Smart Phone, AR/VR, Peripherals...).
4. For Decoration (Plates for Automotive, General Industries).
◆Advantages of Carbon Fiber Composites Materials:
1. Great fire retardant (UL94V-0 passed).
2. Good toughness, strength retention.
3. Special hybrid matrix system for forming process (an unique CFRP).
4. Excellent surface finish (reduce processing cost and time).
5. Can be customize according to requirement for different applications (such as shoes, vehicles, sports, mobile device housing…).
6. Fast Mass Production with special thermosetting plates.
7. COST DOWN! (more than 30~50%) and Higher FPY! (compare with commercial CFRP application process).
◆Quality of Carbon Fiber Composites Materials:
Nan Pao has been implemented the world's leading quality management standard ISO9001 with 8 major quality management principles to assure the high quality of our products. Our strict manufacturing processes certificated with OHSAS 18001 Health & Safety Management System, ISO 50001 energy management system and ISO 14001 environmental management system. We ensure coexistence with the ecosystems and leave a better living situation for future generations.
